JFa12 |
JFa15 |
| System type: |
2-Way 12" Full Range |
2-Way 15" Full Range |
| Woofer: |
12"(300mm);2"(50.8mm)voice coil;40 OZ;8ohm |
15"(385mm);2"(50.8mm)voice coil;40 OZ;8ohm |
| Compression drive: |
1"(25.4mm)Polyester-film; 8 OZ;8ohm |
1"(25.4mm)Polyester-film;8 OZ;8ohm |
| Frequency response: |
55-20KHz |
55-20KHz |
| Rated power: |
150W |
200W |
| Max power: |
300W |
400W |
| Outside the box materials: |
Leather |
Leather |
| Crossover passive: |
3.0 KHz |
3.0 KHz |
| Sensitivity(w/m/2.83v) |
97dB±3dB |
98dB±3dB |
| Connectors |
2x neutik:NL4 |
2x neutik:NL4 |
| Dimensions(WxDxH) |
(370+206)*350*536 |
(470+270)*382*673 |
